G
Warning!
When operating the rear window sunshade
make sure there is no danger of anyone being
harmed by the extending or retracting
procedure.
The extending or retracting procedure can be
immediately halted by briefly pressing rear
window sunshade switch. To reverse direction
of movement, press rear window sunshade
switch again.
!
Make sure that the roller sunblind can
move freely. Otherwise, the roller sunblind
or other objects could be damaged.
X
Turn the key to position 2 in the ignition
lock.
X
To extend or retract: briefly press
button :.
The roller sunblind fully extends or fully
retracts.
Ashtray
Ashtray in the cockpit
i
There is a stowage space under the
ashtray.
!
The stowage space under the ashtray is
not heat resistant. Before placing lit
cigarettes in the ashtray, make sure that
the ashtray is properly engaged. Otherwise,
the stowage space could be damaged.
X
To open: slide cover : forwards until it
engages.
X
To remove the insert: hold insert = by
the ribbing at the sides and lift it up and
out ;.
X
To refit the insert: press insert = into the
holder until it engages.
X
To close: press cover : briefly at the
front.
The cover moves back.
Ashtray in the rear compartment
X
To open: briefly press cover ; at the top.
The ashtray opens.
X
To remove the insert: press release
button = and lift the insert up and out.
X
To re-insert the insert: replace insert :
from above.
X
Press insert : into the holder until it
engages.
Features
291
Loading, stowing and features
BA 212 USA, CA Edition B 2011; 1; 5, en-US
dimargi Version: 3.0.3.6
2010-05-20T13:33:46+02:00 - Seite 291
