Instrument display overview
Mercedes-AMG vehicles: be sure to observe
the information in the Supplement. Otherwise,
you may fail to recognise dangers.
&
WARNING Risk of accident due to an
instrument display malfunction
If the Instrument Display has failed or mal‐
functioned, you may not recognise function
restrictions applying to safety relevant sys‐
tems.
The operating safety of your vehicle may be
impaired.
#
Drive on carefully.
#
Have the vehicle checked immediately
at a qualified specialist workshop.
If the operating safety of your vehicle is
impaired, park the vehicle safely as soon as pos‐
sible. Contact a qualified specialist workshop.
Instrument display (standard)
1
Speedometer
2
Multifunction display
3
Rev counter
4
Coolant temperature display
5
Fuel level and fuel filler flap location indica‐
tor
Instrument display in the widescreen cockpit
1
Speedometer
2
Multifunction display
3
Example: area for additional values
4
Coolant temperature display
5
Fuel level and fuel filler flap location indica‐
tor
%
Further display content can be shown in dis‐
play 3 for additional values (
→ page 262).
The segments in speedometer 1 indicate the
system status for the following:
R
Cruise control (→
page 208)
Instrument Display and on-board computer
259
Nur für internen Gebrauch / For internal use only
