161
Controls in detail
Loading
Removing partition net
왘 Lift tensioner 3 upward to a horizon-
tal position to release tensioning of the
strap.
왘 Disengage tie-down hooks 1 from
rings 2.
왘 Remove mounting hooks 2
(
컄 page 159) from holder 1
(
컄 page 159).
왘 Roll up and close the partition net.
왘 Store partition net behind rear seat
bench.
Cargo area cover blind*
1 Handle
2 Holder
Closing blind
왘 Pull blind on handle 1 across the car-
go area.
왘 Guide blind into holders 2.
Opening blind
왘 Disengage blind and guide retraction
by its handle.
Removing blind
3 Button
4 Mounting sleeve
왘 Roll the blind up.
왘 Push mounting sleeve 4 inward
against spring pressure until it engag-
es.
왘 Remove blind from mounts.
Warning! G
Passenger use of third row seats with cargo
area cover blind installed is restricted.
