Page #3 background imageLoading...
Page #3 background image
Output Module - Extension Module Type mcr R04xx. Operation and Maintenance Manual.
Strona 3 z 19
1. Introduction
This operation and maintenance manual will make the user familiar with the purpose,
design, principle of operation, proper installation and operation of mcr R extension modules in
versions mcr R0424-1, mcr R0424-2, mcr R0448-1, mcr R0448-2, mcr R0448-4, mcr R0424-
K, mcr R0448-K. The manual includes also additional information about the conditions of use,
maintenance and warranty of the product.
Observance of the recommendations included in technical and user documentation will
ensure proper functioning of the smoke ventilation systems and safety of the system users.
“MERCOR" S.A. reserves the right to make changes in the product or in this document
without notice.
2. Intended use
The mcr R04xx extension modules are part of a smoke control system which also
includes other "MERCOR" S.A. products, such as: mcr PROLIGHT, mcr S-THERM, mcr
ULTRA-THERM point smoke exhaust vents, smoke vents integrated in continuous rooflights
and skylights of the mcr PROLIGHT system, smoke control units mcr 9705 and mcr 0204 and
others.
The mcr R04xx extension modules are used for the control and supply of 24 V= voltage
to electric actuators installed in mcr PROLIGHT, mcr S-THERM, mcr ULTRA-THERM smoke
exhaust vents, smoke exhaust windows equipped with MCR W or MCR L actuators, mcr
PROSMOKE FS CE curtains (mcr R0424-1, mcr R0424-2, mcr R0448-1, mcr R0448-2, mcr
R0448-4 modules) or to control and supply with 24V= voltage electric motors of mcr
PROSMOKE CE/C1 smoke curtains (mcr R0424-K, mcr R0448-K modules). The modules can
also be used to power other devices (of other manufacturers), only after checking
interoperability and issuing an appropriate
written statement by "MERCOR" S.A.
Making options:
1. mcr R0424-1 1x 24 A output line,
2. mcr R0424-2 2x output lines, 12 A each,
3. mcr R0424-K for curtains, 1÷10x output lines, 24 A,
4. mcr R0448-1 1x 48 A output line,
5. mcr R0448-2 2x output lines, 24 A each,
6. mcr R0448-4 4x output lines, 12 A each,
7. mcr R0448-K for curtains, 1÷10x output lines, 48 A.
The mcr R04xx extension modules are designed to work with the mcr 9705 and mcr
0204 control units, which control the module functions, correctness of its operation (module
status) and continuity of the panel-module and module-actuators lines.
3. Design and operation
The extension modules comprise the following key components:
1. enclosure with module status indicators on the door;
2. supply and battery charging circuits (configuration depending on the module
version, T1, U1, U2, C1, Z1);
3. control system (US);
4. set of relays (number depends on module version, K1÷K5);
5. battery bank (B1, B2);
6. terminal block with fuses (F1÷F6).
