STORAGE
SECTION 6
Page 94 CMD-3967823 / 90-865237030 OCTOBER 2003
5. Remove the drain plug from the lower part of the intercooler.
79115
a
a-Drain plug
6. Remove the drain plug, or the propeller shaft log seal (stuffing box) cooling hose if
equipped, from the transmission fluid cooler.
79109
a
b
a-Drain plug, or cooling hose (not shown)
b-Transmission fluid cooler
7. Repeatedly clean out drain holes using a stiff piece of wire. Do this until the entire
seawater system is drained.
8. After seawater section of cooling system has been drained completely, coat threads of
drain plugs with sealant and reinstall. Tighten securely.
Description
Where Used Part Number
Perfect Seal Drain plugs 92-34227-1
To Next Page
