MAINTENANCE
SECTION 5
Page 60 CMD-3967823 / 90-865237030 OCTOBER 2003
7. Use a filter wrench or appropriate socket to remove the cartridge type oil filter.
8. Discard the old filter element. Discard the old O-rings from the top piece.
79740
b
c
a
a-Filter element
b-O-rings
c-Top piece
9. Install the three O-rings. Apply a coat of engine oil to the O-rings. Install the element on
the top piece.
Description
Where Used Part Number
Engine oil Oil filter O-rings Obtain Locally
10. Install the top piece with the new element into the oil filter housing.
IMPORTANT: Over tightening the top piece will cause deformation resulting in oil
leakage.
11. Turn the top piece until the sealing face is fitted against the gasket using the filter wrench
or a socket. Torque the top piece.
Description
Nm lb-in. lb-ft
Oil filter top piece 25 18
To Next Page
