FEATURES & CONTROLS
ogc3
POWER TRIM AND TILT (CONTINUED)
Power Trim Operation (continued)
The most significant control hazard is a pull or torque that can be felt on the
steering wheel or tiller handle. This steering torque results from the outboard being
trimmed so that the propeller shaft is not parallel to the water surface.
WARNING
Avoid possible serious injury or death. When the outboard is trimmed in
or out beyond a neutral steering condition, a pull on the steering wheel
or tiller handle in either direction may result. Failure to keep a continuous
firm grip on the steering wheel or tiller handle when this condition exists
can result in loss of boat control as the outboard can turn freely. The boat
can now spin out or go into a very tight maximum turn which, if unex-
pected, can result in occupants being thrown within the boat or out of the
boat.
Consider the following lists carefully.
Trimming In or Down Can:
1. Lower the bow.
2. Result in quicker planing off, especially with a heavy load or a stern heavy boat.
3. Generally improve the ride in choppy water.
4. Increase steering torque or pull to the right (with the normal right hand rotation
propeller).
5. In excess, lower the bow of some boats to a point at which they begin to plow
with their bow in the water while on plane. This can result in an unexpected turn
in either direction (called bow-steering or over-steering) if any turn is
attempted, or if a significant wave is encountered.
ogc4
POWER TRIM AND TILT (CONTINUED)
Power Trim Operation (continued)
WARNING
Avoid possible serious injury or death. Adjust outboard to an intermedi-
ate trim position as soon as boat is on plane to avoid possible ejection
due to boat spin-out. Do not attempt to turn boat when on plane if out-
board is trimmed extremely in or down and there is a pull on the steering
wheel or tiller handle.
6. In rare circumstances, the owner may decide to limit the trim in. This can be
accomplished by purchasing a stainless steel tilt pin (Part Number
17-49930A1) from your dealer and inserting it in whatever adjustment hole in
the transom brackets is desired. The non-stainless steel shipping bolt should
not be used in this application other than on a temporary basis.
Trimming Out or Up can:
1. Lift the bow higher out of the water.
2. Generally increase top speed.
3. Increase clearance over submerged objects or a shallow bottom.
4. Increase steering torque or pull to the left at a normal installation height (with
the normal right hand rotation propeller).
5. In excess, cause boat porpoising (bouncing) or propeller ventilation.
6. Cause engine overheating if any cooling water intake holes are above the
water line.
gog62
1-3
4
a
b
ogc5
POWER TRIM AND TILT (CONTINUED)
Tilting Operation
To tilt outboard, shut off the engine and press the trim/tilt switch or auxiliary tilt
switch to the up position. The outboard will tilt up until the switch is released or it
reaches its maximum tilt position.
1 Engage the tilt support lever (a), by rotating knob (b) to bring the support lever
upward.
2 Lower outboard to rest on the tilt support lever.
3 Disengage the tilt support lever, by raising the outboard off the support lever
and rotating the lever down. Lower the outboard.
Manual Tilting
If the outboard cannot be tilted using the power trim/tilt switch, the outboard can
be manually tilted.
4 Turn out the manual tilt release valve 3 turns (counterclockwise). This allows
manual tilting of the outboard. Tilt the outboard to the desired position and
tighten the manual tilt release valve.
Note: The manual tilt release valve must be tightened before operating the
outboard to prevent the outboard from tilting up during reverse operation.
gog63
1
ogc6
POWER TRIM AND TILT (CONTINUED)
Auxiliary Tilt Switch
1 This switch can be used to tilt the outboard up or down using the power trim
system.
Shallow Water Operation
When operating your boat in shallow water, you can tilt the outboard beyond the
maximum trim range to prevent hitting bottom.
1. Reduce engine speed below 2000 RPM.
2. Tilt outboard up. Make sure all the water intake holes stay submerged at all
times.
3. Operate the engine at slow speed only. If engine speed exceeds 2000 RPM,
the outboard will automatically return down to the maximum trim range.
