Mercury 140 Service Manual

GENERAL INFORMATION
17
Models 140 150 200
Kilowatts 104 112 149
Full Throttle RPM Range
All Models except 200 EFI 5000-5600 RPM
200 EFI Models 5000-5800 RPM
Idle Speed in Forward Gear 600-700 RPM
Number of Cylinders 6
Piston Displacement 2507 cc (153 cu. in.)
Cylinder Bore 88.9 mm (3.500 in.)
Stroke 67.3 mm (2.650 in.)
Recommended Spark Plug NGK BPZ8HS-10
Spark Plug Gap 1.0mm (0.040 in.)
Gear Ratio
Standard Gearcase 1.87:1
High Altitude Gearcase 2:1
Recommended Gasoline Refer to Fuel & Oil
Recommended Oil Refer to Fuel & Oil
Gearcase Lubricant Capacity 710 ml (24 fl. oz.)
Battery Rating
630 Marine Cranking Amps (MCA) or 490 Cold Cranking Amps
(CCA) or Amp Hours 80
Charging System Output 40 Amps
