Mercury 15 MH - Wiring Diagrams

WIRING DIAGRAMS
111
a - Remote control box (optional)
b - Battery
c - Extension cord (optional)
d - Fuse
e - Rectifier
f - Extension cord for light (optional)
g - Receptacle plug (optional)
h - Lamp (12V 80W) [AC] (available on the market)
i - Tachometer (optional)
j - Tachometer, lead wire (optional)
k - Separate cord, white (optional)
l - Separate cord, white (optional)
m -Flywheel magneto
n - Spark plug
o - Ignition coil
p - CD unit
q - Stop switch
r - Stop cord (optional)
