Mercury 150XRI User Manual

1
A
SPECIFICATIONS
90-883728 JULY 2001 Page 1A-1
IMPORTANT INFORMATION
Section 1A - Specifications
Table of Contents
Specifications 1A-1. . . . . . . . . . . . . . . . . . . . . . . . . . . Mercury/Quicksilver Lubricants & Sealants 1A-4. . .
Specifications
Model 150XRI/175XRI/200XRI
HORSEPOWER
(KW)
Model 150XRI
Model 175XRI
Model 200XRI
Full Throttle RPM (150/175/200)
Idle RPM (In Gear) (150/175/200)
RPM Limiter
All Models
150 (111.8)
175 (130.5)
200 (149.1)
5250 – 5750
650 ± 50
Refer to System Information in the
Digital Diagnostic Terminal (DDT) for
latest information
OUTBOARD
WEIGHT
Model 150XRI/175XRI/200XRI
Long Shaft
X-Long Shaft
425.0 lb (192.8 kg)
434.0 lb. (196.8 kg)
CYLINDER
BLOCK
Model 150XRI/175XRI/200XRI
Type
Displacement
Thermostat
V–6 Cylinder, Two Cycle, Loop
Charged
153.0 cu. in. (2507cc)
143°F (61.7°C)
STROKE Length (All Models) 2.650 in. (67.31 mm)
CYLINDER
BORE
Diameter (Std)
Models 150XRI/175XRI/200XRI
Taper/Out of Round/Maximum Wear
Bore Type
3.501 in. (88.925 mm)
0.003 in. (0.076 mm)
Cast Iron
CRANKSHAFT Maximum Runout 0.006 (0.152 mm)
PISTON Piston Type
Models 150XRI/175XRI/200XRI
Standard
0.015 in. (0.381 mm) Oversize
Aluminum
3.494 in. ± 0.001 in.
(88.748 mm ± 0.025 mm)
3.509 in. ± 0.001 in.
(89.129 mm ± 0.025 mm)
COMPRESSION All Models – Using a fully charged bat-
tery, throttle shutters wide open and
cylinder block warm
110 – 135 psi
(753.3 – 924.5 kPa)
Variance between cylinders should not
exceed 15 psi (102.7 kPa)
REEDS Model 150XRI/175XRI/200XRI
Reed Type
Reed Stand 0pen (Max.)
Reed Stop (Max.)
Steel
0.020 in. (0.50 mm)
Not Adjustable
