Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
——Not Used
H/L RH 15A* Lighting Control Module
HORN 15A* Horn Relay
——Not Used
H/L LH 15A* Lighting Control Module
——Not Used
——Not Used
ABS 40A** ABS Control Module
——Not Used
PWR WND 30A** Power Window Relay, Smart Entry
Control (SEC)/Timer Module,
Power Seats
RAD FAN LO 20A** Low Speed Fan Control Relay
——Not Used
IGN SW 30A** Ignition Switch
——Not Used
RAD FAN 75A** High Speed Fan Control Relay
FR BLW 65A** Front Blower Motor Relays
RR DEF 45A** Rear Window Defroster Relay
ALT 140A** Accessory Relay, Ignition Relay,
Tail Lamp Relay, Fuse Junction
Panel
MAIN 100A** Generator
* Mini Fuses ** Maxi Fuses
Roadside Emergencies
181
