Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box Description
52 20A* Trailer tow park lamps
53 10A* Heated mirrors
54 30A* Front wiper motor
55 25A* Rear wiper motor
56 30A* Premium sound radio
57 20A* Cigar lighter
58 30A* SJB #1 – Center High-Mounted Stop Lamp
(CHMSL), License plate lamps, OBD II,
Dome lamp, Auxiliary blend doors, Switch
illumination (feeds F–8, F–9, F–10 and
F–11)
59 20A* Radio (non-premium)
60 30A* SJB #4 – Back-up lamps, Theft sounder,
Door locks
61 20A* 3rd row power point
62 30A* SJB #3 – Right cornering/auxiliary lamps,
Right low beam, Left front park/turn
lamps, Left rear park/stop/turn lamps,
Instrument panel courtesy lamps, Step
well lamps, Left signal mirror, Clock,
Cluster, Message center (SJB F–15),
Switch illumination for: overhead console,
DVD/Rear climate control system,
Headlamp switch illumination, Climate
control illumination
63 20A* Instrument panel power point
64 20A* Ignition switch #1 feed
65 30A* SJB #2 – Left cornering/auxiliary lamps,
Left low beam, Right front park/turn
lamps, Right rear park/stop/turn lamps,
Puddle lamps, Mirror signals, Visors, 2nd
and 3rd row lamps, Cargo lamp, Defroster
indicator
2004 Monterey (mty)
Owners Guide (post-2002-fmt)
USA English (fus)
Roadside Emergencies
188
