90-822900R3 DECEMBER 1997 IMPORTANT INFORMATION - 1A-5
Model 3 Litre Work/225 Carb/225 EFI/250EFI
C
A
R
B
U
R
E
T
O
R
Model 3 Litre Work
Idle RPM
Wide Open Throttle (WOT) RPM
Idle Mixture Screw Adjustment
Float Adjustment
WMV 11
– Cylinder #1
– Main Jet
– Idle Jet
– Vent Jet
– Cylinder #2
– Main Jet
– Idle Jet
– Vent Jet
– Cylinder #3
– Main Jet
– Idle Jet
– Vent Jet
– Cylinder #4
– Main Jet
– Idle Jet
– Vent Jet
– Cylinder #5
– Main Jet
– Idle Jet
– Vent Jet
– Cylinder #6
– Main Jet
– Idle Jet
– Vent Jet
650 ± 50
5000 – 5500
1-1/2±1/4
Float is Level with top of Bowl w/Bowl In-
verted
.082
.040
.080
.082
.046
.080
.082
.058
.080
.086
.048
.080
.082
.054
.080
.082
.048
.080
