OPERATION
eng 59
Oil Injection System
FILLING THE OIL TANKS
1. Remove the fill cap from the remote oil tank and fill the tank with the
recommended oil. Install the fill cap and tighten securely.
a - Fill cap
IMPORTANT: Do not remove the vent cap from the engine‑mounted oil
reservoir tank when filling the tank. Removal of the vent cap may damage the
threads in the oil reservoir tank. Damaged threads may result in future oil
leakage.
2. Check the oil level in the engine‑mounted oil reservoir tank. The tank
must contain at least 118 ml (4 oz) of oil prior to starting the engine.
3. If the oil level is less than 118 ml (4 oz), loosen the vent cap. Use a squirt
can and fill the tank with at least 118 ml (4 oz) of the recommended oil.
Tighten the vent cap.
a - Engine‑mounted oil reservoir tank
b - Vent cap
