MAINTENANCE
eng 81
IMPORTANT: To prevent the propeller hub from corroding and seizing to the
propeller shaft, especially in salt water, always apply a coat of Extreme Grease
to the entire propeller shaft at the recommended maintenance intervals and
also each time the propeller is removed.
1. Lubricate the propeller shaft splines with Extreme Grease.
2. Install the propeller hub assembly, propeller, washer, Belleville washer,
washer, and propeller nut onto the propeller shaft.
a - Propeller hub
assembly
b - Propeller
c - Washer
d - Belleville washer
e - Washer
f - Propeller nut
Tube Ref
No.
Description Where Used Part No.
Extreme Grease Propeller shaft splines 8M0071842
3. Place a block of wood between the gearcase and propeller and torque the
propeller nut.
Description
Nm lb. in. lb. ft.
Propeller nut 75 55
4. Disengage the safety stop switch by placing it in the "RUN" position and
return the keys to the ignition switch.
