GENERAL INFORMATION
Page 1C-8 90-827242R02 FEBRUARY 2003
6. Install forward thrust hub, propeller, rear thrust hub and propeller nut onto the shaft.
a
b
c
d
a-Forward thrust hub
b-Propeller
c-Rear thrust hub
d-Propeller nut
7. Place a block of wood between gear case and propeller and tighten propeller nut.

Other manuals for Mercury 6

Preview: Manual
Manual31 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mercury 6 and is the answer not in the manual?

Mercury 6 Specifications

General IconGeneral
Cylinders1
StartingManual
Displacement123 cc
Horsepower6 HP
Shaft Length15 inches (Short)
Gear ShiftForward, Neutral
