OUTBOARD INSTALLATION
Page 1D-6 90-827242R02 FEBRUARY 2003
2. Secure steering link rod between engine steering bracket and steering cable end.
95
95
95
a
b
c
d
e
f
g
h
i
j
95
2-4-C with Teflon
a-Steering link arm
b-Ball joint (flat end facing up)
c-Steering bracket
d-Spacer - 9.5 mm (3/8 in.)
e-Rubber spacer
f-Flat washer 20.6 mm (13/16 in.)
g-Locknut. Tighten to specified torque.
h-Flat washer [15.9 mm (5/8 in.)] (2)
i-Spacer
j-Locknut. Tighten until nut seats, then back off 1/4-turn
Locknut Torque
27 Nm (20 lb-ft)

Mercury 6 Specifications

General

Cylinders	1
Starting	Manual
Displacement	123 cc
Horsepower	6 HP
Shaft Length	15 inches (Short)
Gear Shift	Forward, Neutral
