12
90-10104R40
GB
oe
FUEL & OIL
oeb6
GASOLINE RECOMMENDATIONS
United States and Canada
Use a major brand of automotive unleaded gasoline with a minimum posted octane
rating of 87. Mid-grade automotive gasolines that contain fuel injector cleaner are
preferred for added internal engine cleanliness. Leaded gasoline is not
recommended.
International
Use a major brand of automotive unleaded gasoline with a minimum posted octane
rating of 90RON. Automotive gasolines that contain fuel injector cleaner are
preferred for added internal engine cleanliness. Leaded gasoline is acceptable in
areas where unleaded gasoline is not available.
Alcohol in Gasoline
We do not recommend the use of gasoline which contains alcohol because of the
possible adverse effect the alcohol may have on the fuel system. In general, if only
gasoline containing alcohol is available, it must not contain more than 10% ethanol
or 5% methanol, and the addition of a Water Separating Fuel Filter is
recommended.
If gasoline containing alcohol is used or if you suspect the presence of alcohol in
your gasoline, increase your inspection of the fuel system, visually checking for
fuel leaks or abnormalities.
Gasoline containing alcohol may cause the following problems to your outboard
and fuel system:
• Corrosion of metal parts.
• Deterioration of elastomers and plastic parts.
• Wear and damage of internal engine parts.
• Starting and operating difficulties.
• Vapor lock or fuel starvation.
Some of these adverse effects are due to the tendency of gasoline containing
alcohol to absorb moisture from the air, resulting in a phase of water and alcohol
which separates from the gasoline in the fuel tank.
The adverse effects of alcohol are more severe with methanol and are worse with
increasing content of alcohol.
oec13
OIL RECOMMENDATION
Mercury or Quicksilver Premium TC-W3 2-cycle oil is recommended for your
engine. For added protection and lubrication, Mercury or Quicksilver Premium
Plus TC-W3 2-cycle oil is recommended. If Mercury or Quicksilver outboard oil is
not available, substitute another brand of 2-cycle outboard oil that is NMMA
Certified TC-W3. Severe engine damage may result from use of an inferior oil.
eeg8
NEW ENGINE GASOLINE/OIL BREAK-IN MIXTURE
Use a 25:1 (4%) gasoline/oil mixture in the first tank of fuel.
After the break-in fuel mixture is used up, use a 100:1 (1%) gasoline/oil mixture
in engines used for pleasure applications. To provide additional protection for
commercially used products, a 50:1 (2%) gasoline/oil mixture is recommended.
eeb1
Gasoline/Oil Mixing Ratio Chart
Gas/Oil
Ratio
5 Liters Gas
10 Liters Gas 20 Liters Gas
25:1 (4%) 200 ml Oil 400 ml Oil 800 ml Oil
50:1 (2%) 100 ml Oil 200 ml Oil 400 ml Oil
100:1 (1%) 50 ml Oil 100 ml Oil 200 ml Oil
oee6
FILLING FUEL TANK
WARNING
Avoid serious injury or death from a gasoline fire or explosion. Always
stop the engine and DO NOT smoke or allow open flames or sparks in the
area while filling fuel tanks.
Fill fuel tanks outdoors away from heat, sparks, and open flames.
Always stop engine before refilling tanks.
Do not completely fill the fuel tanks. Leave approximately 10% of the tank volume
unfilled. Fuel will expand in volume as its temperature rises and can leak under
pressure if the tank is completely filled.
Filling Fuel Tanks Permanently Installed
Slowly pour the correct amount of oil along with the gasoline as the tank is being
filled.
Filling Portable Fuel Tanks
Remove portable fuel tanks from boat to refill them.
Pour the full amount of oil along with approximately one gallon of gasoline into the
fuel tank. Mix thoroughly, then pour the remainder of gasoline into the tank.
Portable Fuel Tank Placement in the Boat
Place the fuel tank in the boat so that the tank vent will stay higher then the fuel
level in the tank under normal boat operating conditions.
gog11
123
og
FEATURES & CONTROLS
ogd1
TILLER HANDLE MODELS
1
Tiller Handle - Handle can be tilted up for convenient handling during
transportation and storage.
2 Starter Rope - Pulling the starter rope cranks the engine over for starting.
3 Primer/Idle Speed Knob - Pulling the knob out supplies a small amount of fuel to
the engine for cold starting. Rotate knob to adjust idle speed after engine warms
up.
gog12
54 6
4 Lanyard Stop Switch - Read the Lanyard Stop Switch safety explanation and
Warning in the General Information Section.
5 Lanyard - Read the Lanyard Stop Switch safety explanation and Warning in the
General Information Section.
6 Engine Stop Switch - Push in to stop engine.
gog13
789
R
F
R
F
a
b
ogd13
TILLER HANDLE MODELS
7
Throttle Grip Friction Knob - Turn friction knob to set and maintain the throttle
at desired speed. Turn knob towards (a) to tighten friction and move knob
towards (b) to loosen friction.
8 Throttle Grip Gear Shift (if equipped) - controls gear shift and engine speed.
Note: Side handle gear shift outboards (Step 9) are furnished in some worldwide
market areas. Side handle gear shift is also available as a Quicksilver or Mercury
Precision Accessory.
9 Side Handle Gear Shift (if equipped) - controls gear shift.
