All occupants of the vehicle including the driver should always
wear their safety belts even when an airbag SRS and Safety
Canopy娂 system is provided.
To reduce risk of injury, do not obstruct or place objects in the
deployment path of the inflatable Safety Canopy娂.
How does the Safety Canopy姟 system work?
The design and development of the
Safety Canopy娂 system included
recommended testing procedures
that were developed by a group of
automotive safety experts known as
the Side Airbag Technical Working
Group. These recommended testing
procedures help reduce the risk of
injuries related to the deployment of
side airbags (including the Safety
Canopy娂).
The Safety Canopy娂 system
consists of the following:
• An inflatable nylon curtain with a
gas generator concealed behind
the headliner and above the doors
(one on each side of vehicle).
• A headliner designed to flex open above the side doors to allow Safety
Canopy娂 deployment.
• The same readiness airbag light, electronic control and diagnostic unit
as used for the front airbags.
• Two crash sensors mounted under the front seats (one on each side).
• Two crash sensors located at the c-pillar behind the rear doors (one
on each side).
• Rollover sensor in the restraints control module (RCM).
The Safety Canopy娂 system, in combination with safety belts, can help
reduce the risk of severe injuries in the event of a significant side impact
collision or rollover event.
2007 Monterey (mty)
Owners Guide (post-2002-fmt)
USA (fus)
Seating and Safety Restraints
162
