Mercury Optimax 115 Installation Manual

75/90/115 OPTIMAX
Page 3 of 18
Installation Specifications
a
b
a
a – Transom Opening – Minimum
Single Engine (Remote) – 33-3/8 in. (848 mm)
Dual Engines – 59-3/4 in. (1518 mm)
b – Engine Center Line For Dual Engine
26 in. (660mm) Minimum
Lifting Outboard
Use Flywheel Puller/Lifting Eye (91-83164M).
