9
INTRODUCTION
Characteristics
•
Distortion typically <0.01%, or <0.02% up to full power at all
frequencies.
•
Noise and hum <-94dBr at all volume settings.
•
Acoustic output typically >111dB spl @ 1m.
•
Acoustic noise <15dB spl @ 1m.
•
Frequency response in room response within 3dB, 28Hz-20kHz.
Control
•
2 x Meridian Comms.
•
9-pin D connector for RS232 PC control, null modem, 9600 baud, 2N1, no
handshake.
Cabinet
•
Thick MDF side panels sandwiched around steel plates for maximum
damping across all frequencies.
•
Steel plates give magnetic shielding.
•
Side panels available in black ash and rosewood.
•
Separate mid-range enclosure built into main cabinet.
•
DSP5500 and DSP5500C: 284mm x 1100mm x 450mm (11.2" x 43.3" x
17.7") (W x H x D).
•
DSP5500HC: 1100mm x 285mm x 415mm (43.3" x 11.2" x 16.3")
(W x H x D).
•
65kg (143lb) each.
Power
•
100-125; 200-250V AC 50-60Hz.
•
20VA standby; 600VA max.
Meridian Audio reserves the right to amend product specifications at any
time.
