DDC70/DDC80
Her türlü değişiklik hakkı saklıdır.
KLV-09/Yayın Tarihi : 09.03.2023/Revizyon No: 00 /Revizyon Tarihi:
Nudging Mode: While the door is moving in one direction, if it encounters any obstacle, it changes its
direction and moves in the opposite direction. It then tries to move again in the direction it detected
the jamming. If it detects a jamming again in the same direction, and this situation is repeated 3 times
in a row, it detects that there is a situation that prevents it from completing its movement and switches
to nudging mode. In this mode, the door moves in the direction which jamming was detected, at low
speed and high pressure (nudging pressure), by giving an audible warning. Nudging Mode is also
activated when the "Slow Command" signal is given. The purpose in Nudging mode is to try to
eliminate the obstacle encountered.
4.4.4.3.Socket Settings
It contains the parameters that determine the operating modes for the Sensor (Limit switch) and Input
(Command) sockets. There are 3 values for these parameters that can be entered according to the
operating modes of the signals.
Yes-When Active:1 : This option should be selected if there is no power at the socket input when
the specified signal is not available (led is off), but if this option is available when the signal is active
(led is on).
Yes-When Active:0 : This option should be selected if the socket input is energized (led is on) when
the specified signal is not available, but if this energy is cut off when the signal is active (led is off).
None-Not Connected : Indicates that the specified signal is not used.
If only one signal comes from the main control panel instead of two signals such as "Close Door" and
"Open Door"; 'I2 - Open Door' parameter should be selected as "None-Not Connected". In this case,
as long as "I1 - Close Door" signal is present, the door will close, and when the signal is off, the door
will open. If possible; It is safer to set it so that two signals are sent from the board instead of a single
signal. Unused signals in the socket settings must be selected as "None-Not Connected".
19
