DDC70/DDC80
Her türlü değişiklik hakkı saklıdır.
KLV-09/Yayın Tarihi : 09.03.2023/Revizyon No: 00 /Revizyon Tarihi:
1-Telescopic Door
2-Central Door
3-Door Electrical Locking Contact
4-Door Electrical Monitoring Contact
Cabin door mechanisms are divided into two as telescopic and central. In telescopic cabin door
mechanisms, there are safety contacts on a skate at one closing point. In the central cabin door
mechanisms, there are safety contacts at two closing points and on one skate. In cabin door
mechanisms, the plug contacts on the skate and the plug contacts at the monitoring contact
closing points are used as locking contacts
6.1.Door Electrical Monitoring Contact
DDC70 Door Monitor Connection
33
OCOM
NC
NC
NC
NO
NO
NO
O3
O2
O1
I
II
1
2
3
4
WI-FI POWER
