4
1
2
3
4
Optional accessory
2.75m Segmented pole pack
(separate carton)
3m Chain Pack and Joiner
Pole Adaptor Kit
6
5
7
10
9
11
8
(1) MT5580 opener
(2) Angled door arm
(3) Door mounting bracket
(4) Straight door arm
(5) Header bracket
(6) Stop collar, nut & bolt
(7) Pole kit adaptor
(8) Trolley assembly
(9) Idler pulley assembly
(10) Chain and joiner
POLE OPTIONS
(11) 2.75m segmented pole kit
NOT PICTURED
3m one piece pole
HARDWARE PROVIDED
4
