INSIDE
INSIDE
4
INSTALLATION GUIDE
6
NOTE: Make sure the cutout in the
top and bottom bracket faces in.
Use spacer provided to set
the gap under the glass
INSIDE
5
TOP TIP ! Fit seal to side
closest to shower head.
Bottom of the seal should
be flush with the bottom of
the glass.
M7020
M7020
M7110
Drill three holes on the
inside of the wall profile
and fix using screws
A2401201
0-20mm Max
