MERLYN 8 Series User Manual

INSTALLATION GUIDE
7
1
7
A
B
C
D
E
F
G
H
INSIDE
I
Close door fully, align
magnets and mark
position the profile on
the wall.
Align the Magnet profile
to the line and mark hole
position
Fit part to the
bottom of the magnet
profile assembly.
M7119
M7119
M7020
M7111
6
Cut excess only
from the hinged
side of both seals.
Make sure the
angled fin is to
the inside
M7107
Add dab
of silicone.
End of the bottom
seal should be flush
with the outside face
of the upright seal.
1
0 m
m
Note: If fitting as a shower wall skip to step 10 for sealing instructions.
If fitting as a corner door skip to step 11.
Bottom
13mm
For Bifold in recess
or with side panel
ensure the magnet
is 13mm below the
glass panel

MERLYN 8 Series Specifications

General

Magnetic Seals	Yes
Glass Thickness	8mm
Finish	Brushed Nickel
Reversible	Yes
Glass Finish	Clear
Frame Finish	Brushed Nickel
Material	Aluminum
Installation Type	Wall Mount
Height	1950mm
