Mesa/Boogie Express Plus User Manual

PAGE 35
120V~
60 Hz
3 A
7,602,927
6,724,897
SOLOEQ
5:50+
FOOTSW.
3 A
3 x DUAL JACKS
pt# 619357
3 JACKS
pt# 619356
REAR PANEL: Express 5:50+
DOM pt#
790300
EXP pt#
795200
HOLDER EXP
pt#790346
HOLDER pt#
790347
JACK pt#
614608
ALL KNOBS
PT# 408015
EQ ON
FT SW
O O
EQ
SLIDERS
EQ
PRESET
EQ ON
PRESET
DEPTH
FT SW
SLIDERS
PRESET
SLIDERS
PRESET
5 W
25
CH 1 CH 2
50 W
SOLO
80Hz 240 750 2200 6600
1 2
1 2
590739
590148
590736
592597
590738
590738
592592
590739 590738 590737
590739
590738
590148
JACK
pt# 610120
SWITCH
pt# 607231
LENS pt#
703782
BULB pt#
703047
HOLDER pt#
703047
SWITCH
pt# 607231
FRONT PANEL: Express 5:50+
EQ KNOBS - 408550
EQ SLIDER POT - 588536
2 x SWITCH
pt# 607233
2 x SWITCH
pt# 607233
2 x SWITCH
pt# 600631
3 SWITCHES
pt# 607233
2 x POTS - 594375
2 x KNOBS - 408602

Mesa/Boogie Express Plus Specifications

General

Channels	2
Reverb	Yes
EQ	5-Band Graphic EQ
Type	Tube Amplifier
Effects Loop	Yes
Tubes	4x12AX7, 2xEL84
Modes per Channel	2
Speaker	1 x 12" Celestion
