OPERATION
EEPROM LAYOUT
The second half of M25P16 sector layout is as follows:
0x100000 USER CONFIGURATION BLOCK 0
0x110000 USER CONFIGURATION BLOCK 1
0x120000 USER CONFIGURATION BLOCK 2
0x130000 USER CONFIGURATION BLOCK 3
0x140000 USER CONFIGURATION BLOCK 4
0x150000 USER CONFIGURATION BLOCK 5
0x160000 UNUSED/FREE
0x170000 UNUSED/FREE
0x180000 UNUSED/FREE
0x190000 UNUSED/FREE
0x1A0000 UNUSED/FREE
0x1B0000 UNUSED/FREE
0x1C0000 UNUSED/FREE
0x1D0000 UNUSED/FREE
0x1E0000 UNUSED/FREE
0x1F0000 UNUSED/FREE
