Mestek Space Pak ESP-D - Page 7

7
MODEL AB C
ESP-2430D
24-1/8"
12"
16-7/8"
ESP-3642D
33-1/8"
16-1/2"
24-1/4"
ESP-4860D
43-1/8"
21-1/2"
34-1/8"
D
15-3/8"
16-1/2"
21-1/2"
10-7/8" I.D.
SUPPLY
6"
3-1/2"
1-5/8"
7"
1"
B
11-5/16"
C
28-1/2"
30"
A
D
14"
3/8" SWEAT (LIQUID)
7/8" SWEAT (SUCTION)
3/4" N.P.T. DRAIN CONN.
8" MIN. CLEARANCE
12" MIN. CLEARANCE
38" MIN. CLEARANCE
ELECTRICAL
CONTROL BOX
RETURN
PLENUM
1-5/8"
5-1/2"
FIGURE 2.3: VERTICAL AIR FLOW UNIT DIMENSIONS AND CLEARANCES
CLAMP BAND
CLAMP BAND
RETURN AIR BOX
WITH GRILL & FILTER
SPACE-PAK FAN
COIL UNIT
FLEXIBLE RETURN
DUCT (90° BEND)
48"
PLATFORM (FIELD ERECTED
AS SHOWN IN STEP 4)
SUPPLY AIR OUTLET
(ALTERNATE LOCATION)
SUPPLY AIR OUTLET
FIGURE 2.4: TYPICAL UNIT INSTALLATION
14 Ft. MAXIMUM FLEXIBLE
RETURN DUCT
FAN COIL UNIT
AAAA
AAAAAA
A
A
A
A
A
A
SUPPORT
RETURN AIR BOX
90°
90°
2 Ft.
MAX.
PLATFORM (FIELD ERECTED
AS SHOWN IN STEP 4)
AAAAAA
AAAAAAAAAA
SUPPORT
AAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAA
FIGURE 2.5: HORIZONTAL AIR FLOW UNIT INSTALLATION
