ENGLISH
13
ENG
Only moderate pressure is required for hammer
drilling and chiselling. Exerting a high force does
not increase performance.
When drilling deep holes, remove the drill bit
periodically from the hole to release the stone
dust.
Drill tiles and other brittle materials without impact.
Keyless chuck cleaning (accessory):
After prolonged use hold the chuck vertically, with
the opening down, and fully open and close it
several times. The dust collected falls from the
opening. The application of cleaning spray to the
jaws and jaw openings at regular intervals is
recommended.
The vent slots of the machine should be cleaned
from time to time.
Electronic signal indicator (7)
Slow flashing - carbon brushes worn
The carbon brushes are almost completely worn.
If the brushes are completely worn, the machine
switches off automatically. Have the brushes
replaced by an authorized service centre.
f
Use only genuine Metabo accessories.
If you need accessories, check with your dealer.
For the dealer to select the correct accessory, he
needs to know the exact model designation of
your power tool.
See page 4.
A Tools with SDS-Plus shank
B Twist drills for metal and wood
C TCT core cutter
D Keyless chuck
E Special grease (for lubricating the tool shanks)
For complete range of accessories, see
www.metabo.com or the main catalogue.
Repairs to electrical tools must be carried out by
qualified electricians ONLY!
Any Metabo power tool in need of repair can be
sent to one of the addresses listed in the spare
parts list.
Please attach a description of the fault to the
power tool.
Metabo's packaging can be 100% recycled.
Worn out power tools and accessories contain
considerable amounts of valuable raw and plastic
materials, which can be recycled.
These instructions are printed on chlorine-free
bleached paper.
Only for EU countries: Never dispose of
power tools in your household waste! In
accordance with European Guideline
2002/96/EC on used electronic and electric
equipment and its implementation in national legal
systems, used power tools must be collected
separately and handed in for environmentally
compatible recycling.
Explanatory notes on the information on page 2.
Changes due to technological progress reserved.
P
1
=rated input
P
2
=rated output
n
1
=no-load speed
n
2
=load speed
ø max = max. solid drill diameter
s max = max. impact rate
W = single impact strength
m = weight
D = spindle collar diameter
b = drill chuck chucking capacity
Typical A-weighted sound levels:
L
pA
= sound pressure level
L
WA
=sound power level
K
pA
, K
WA
= unsafe
During operation, the acoustic level may
exceed 85 dB(A).
Wear hearing protection!
ahw = typical weighted acceleration in the
hand-arm area
Measured values established according to
EN 60745.
The stated technical specifications are subject to
tolerances (as specified in the respective current
standards).
9 Tips and Tricks
10 Maintenance
11 Trouble Shooting
12 Accessories
13 Repairs
14 Environmetal Protection
15 Technical Specifications
