Item
No.
Part Name Q’TY
1
HEX. SOCKET HD. BOLT (W/FLANGE) M6×45 3
2TOP COVER 1
3
HEX. SOCKET HD. BOLT (W/SP.WASHER)
M6
× 25
4
4EXHAUST COVER 1
5GASKET (B) 1
6GASKET (F) 1
7EXHAUST PIECE 1
8GASKET (C) 1
9EXHAUST VALVE 1
10 HEAD CAP AND GASKET SET 1
11 O -RING (1AP-48) 1
12 PISTON ASS'Y 1
13 O-RING 3
14 CYLINDER O-RING (I.D 63.1) 1
15 CYLINDER PLATE 1
16 CYLINDER O-RING (I.D 79.3) 1
17 CYLINDER 1
18 CYLINDER O-RING (I.D 69.3) 1
19 CYLINDER RING 1
20 CYLINDER SPRING 1
21 BASE WASHER 1
22 CYLINDER GUIDE 1
23 LABEL 1
24 O-RING (I.D 1.8) 1
25 WARNING LABEL 1
26 BODY ASS'Y 1
27 CYLINDER O-RING (I.D 63.9) 1
28 PISTON BUMPER (B) 1
29 GASKET (A) 1
30 NYLOCK HEX. SOCKET HD. BOLT M6
× 18 2
31 SPRING WASHER M6 2
32 GUARD (A) 1
33 NOSE (P1) 1
34 NYLOCK HEX. SOCKET HD. BOLT M8
× 22 4
35 ROLL PIN D3X18 (10 PCS.) 1
36 NYLOCK BOLT (W/FLANGE) M8
× 16 1
37 NYLON NUT M6 2
38 HANDLE ARM (B) 1
39 GASKET (G) 1
40 GRIP RUBBER 1
41 GASKET (H) 1
42 CAP (B) 1
43 HEX. SOCKET HD. BOLT M5
× 18 3
44 AIR PLUG NPT 3/8 1
45 PLUNGER (B) SPRING 1
46 PLUNGER (B) 1
47 PUSHING LEVER (C) 1
48 SPRING 1
49 PUSHING LEVER (B) 1
50 ADJUSTER 1
51 ADJUSTER SPRING 2
52 STEEL BALL D3.175 2
53 PUSHING LEVER (A) 1
54 WASHER 1
55 HEX. SOCKET HD. BOLT M6
× 12 1
56 NAME PLATE 1
57 TRIGGER PIN 1
58 VALVE GUARD 1
59 ROLL PIN D3
× 45 1
Item
No.
Part Name Q’TY
60 TRIGGER ARM SPRING 2
61 CHANGE ROD 1
62 TRIGGER 1
63 ROLL PIN D2.5 1
64 PLUNGER SPRING 1
65 O-RING (P-4) 1
66 PLUNGER (A) 1
67 O-RING (I.D 10.7) 2
68 VALVE BUSHING (A) 1
69 TRIGGER SPRING 1
70 TRIGGER ARM 1
71 CHANGE STOPPER 1
72 LOCK PIN 1
73 VALVE PACKING 1
74 URETHANE BALL (C) D7.14 1
75 O-RING (S-12) 1
76 VALVE PLATE 1
77 TRIGGER VALVE BUSHING 1
78 TRIGGER PLUNGER 1
79 O-RING 1
80 NAIL FEEDER 1
81 NEEDLE ROLLER 1
82 RIBBON SPRING 1
83 NYLON NUT M4 1
84 SPRING WASHER M4 1
85 NYLON NUT M5 1
86 SPRING WASHER D5 1
87 MAGAZINE BASE 1
88 SLEEVE 1
89 HEX. SOCKET HD. BOLT M5
× 45 1
90 HEX. SOCKET HD. BOLT M4
× 15 1
91 STOP LEVER 1
92 COLLAR 1
93 STOPPER SPRING 1
94 HEX. SOCKET HD. BOLT M6
× 12 2
95 WASHER 1
96 MAGAZINE ASS'Y 1
97 SPRING (A) 1
98 PUSHING LEVER 1
99 GUARD 1
100 NOSE (P2) 1
501 SAFETY GLASSES 1
502 HOOK ASS'Y 1
503 HOOK 1
504 HEX. SOCKET HD. BOLT (W/FLANGE) M5
× 14 3
77
