Metabo NR83A5 - Page 79

Item
No.
Part Name Q’TY
1
HEX. SOCKET HD. BOLT (W/FLANGE) M6×45 3
2TOP COVER 1
3
HEX. SOCKET HD. BOLT (W/SP.WASHER)
M6
× 25
4
4EXHAUST COVER 1
5GASKET (B) 1
6GASKET (F) 1
7EXHAUST PIECE 1
8GASKET (C) 1
9EXHAUST VALVE 1
10 HEAD CAP AND GASKET SET 1
11 O -RING (1AP-48) 1
12 PISTON 1
13 O-RING 3
14 CYLINDER O-RING (I.D 63.1) 1
15 CYLINDER PLATE 1
16 CYLINDER O-RING (I.D 79.3) 1
17 CYLINDER 1
18 CYLINDER O-RING (I.D 69.3) 1
19 CYLINDER RING 1
20 CYLINDER SPRING 1
21 BASE WASHER 1
22 CYLINDER GUIDE 1
23 LABEL 1
24 O-RING (I.D 1.8) 1
25 WARNING LABEL 1
26 BODY ASS'Y 1
27 CYLINDER O-RING (I.D 63.9) 1
28 PISTON BUMPER (B) 1
29 GASKET (A) 1
30 NYLOCK BOLT (W/FLANGE) M6
× 12 1
31 GUARD 1
32 NYLOCK HEX. SOCKET HD. BOLT M8
× 22 4
33 NOSE 1
34 NOSE RUBBER 1
35 NYLOCK BOLT (W/FLANGE) M8
× 16 1
36 NYLON NUT M6 3
37 HANDLE ARM 1
38 GASKET (G) 1
39 GRIP RUBBER 1
40 GASKET (H) 1
41 CAP (B) 1
42 HEX. SOCKET HD. BOLT M5
× 18 3
43 AIR PLUG NPT 3/8 1
44 PLUNGER (B) SPRING 1
45 PLUNGER (B) 1
46 PUSHING LEVER (C) 1
47 SPRING 1
48 PUSHING LEVER 1
49 NAME PLATE 1
50 TRIGGER PIN 1
51 VALVE GUARD 1
52 ROLL PIN D3
× 45 1
53 TRIGGER ARM SPRING 2
54 CHANGE ROD 1
55 TRIGGER 1
56 ROLL PIN D2.5 1
57 PLUNGER SPRING 1
58 O-RING (P-4) 1
59 PLUNGER (A) 1
Item
No.
Part Name Q’TY
60 O-RING (I.D 10.7) 2
61 VALVE BUSHING (A) 1
62 TRIGGER SPRING 1
63 TRIGGER ARM 1
64 CHANGE STOPPER 1
65 LOCK PIN 1
66 VALVE PACKING 1
67 URETHANE BALL (C) D7.14 1
68 O-RING (S-12) 1
69 VALVE PLATE 1
70 TRIGGER VALVE BUSHING 1
71 TRIGGER PLUNGER 1
72 O-RING 1
73 SLEEVE 1
74 MAGAZINE COVER 1
75 NAIL RAIL 1
76 NAIL FEEDER (A) 1
77 ROLL PIN D4
× 40 1
78 NAIL FEEDER (B) 1
79 FEEDER SPRING 1
80 NAIL FEEDER ASS'Y 1
81 RIBBON SPRING 1
82 NEEDLE ROLLER D4
× 20 1
83 MAGAZINE 1
84 LABEL (A) 1
85 HEX. SOCKET HD. BOLT (W/FLANGE) M6
× 12 3
86 NAIL STOPPER 1
501 SAFETY GLASSES 1
502 HOOK ASS'Y 1
503 HOOK 1
504 HEX. SOCKET HD. BOLT (W/FLANGE) M5
× 14 3
79
