Metasys COMPACT Dynamic - Page 14

EN | Preparation for use
14
5.3. Installation, assembly and commissioning
1
Read the instructions carefully before installation and commissioning!
Meet spatial requirements see 5.2. Installation requirements
2 Checkthecoarselterinthespittoon
3 Installthepre-lter(ifnotpresentinthehosestorage)
COMPACT Dynamic Built-in version
4 Fit a contact protection plate behind module 1 (if the subsurface is electrically conductive)
5
Connect the spittoon drain hose
(Meshsizeofthecoarseltermax.3mm)
6 Connect the drain hose
7 Connect the suction line from the hose storage (suction hose)
8 Connect the suction line to the suction machine (suction hose)
9 Connect electrical connections (see 5.4. Electronics)
