Metasys DX-9100 User Manual

DX LCD Display
iv
Figure 5: Connections to the Permanently Mounted DX LCD Display
Figure 6: Connector Location
DX-9100/9121
Controller
esc
!
DX LCD
Display
Serial Cable
15 m / 50 ft
maximum length
idtdxca
Alarm contacts to external
annunciation device (35 V, 1 amp maximum)
24 VAC
24 VAC Com
91 92 93
94 95 96
Alarm
Horn
91 92 93
RS-232 Serial
Port Connector
2
3
4
5
1
