UV Plus V05 08/2015 - 12 -
Installation instruction
Equipotential bonding
Also on the rear side of the UV Plus there
is a stud for the equipotential bonding.
Integrate the UV Plus with a suitable cable
into the equipotential bonding system.
Observe on Combi-Duo:
Attention
UV Plus must not be installed on Combi Duo with
caster. Danger of tipping over!
- Connect the vent pipe of the Combi-Duo to the
connection piece of the UV Plus using hose
(item 10) and hose clamp (item 11) of the
UV Plus kit. pic. 9
- Installation of the bus cable:
There are two bus cables connected to the con-
trol pcb. Use the longer cable for the bottom unit
and the shorter for top unit. Connect the cable
as described under point 4.
7. Technical intervention
Before any intervention or maintenance work,
disconnect the appliance from the power sup-
ply.
7.1 Fan motor.
Fan motor is accessible after removing the
fat filter and pre filter. pic. 17
7.2 Changing halogen bulb. pic. 15
After loosen the holding frame, the halogen bulb
can be changed.
7.3 Changing differential pressure switch of pre filter
- Set adjustment disc of pressure switch to zero
position
- Switch on Ultravent and unit
- Remove fat filter. On the pre filter cover
approx 2/3 of the surface of the filter with a
piece of paper.
- Rotate adjustment disc out of zero position
until LED of pre filter switches on.
- When removing the paper LED must switch of.
8. Wiring diagram
see Page 80
9. Service parts
Description Art. No.
Control pcb 42.00.050
Bus cable 40.04.148
Fuse 5 x 20 2,5A 3019.0117
Halogen bulb 3024.0201
Inner gasket for interior light 40.00.094
Glass pane for interior light 40.00.095
Gasket frame for interior light 40.00.092
Fat filter left 60.72.440
Fat filter right with lock 60.72.441
Adapter plate left hinged door
(Pos. 1) 61/101 60.72.891
Adapter plate right hinged door
(Pos. 1) 61/101 60.72.936
Adapter plate right hinged door
(Pos. 1) 62/102 60.72.937
Gasket adapter (Pos. 2) 61/101 60.72.431
Gasket adapter (Pos. 2) 62 60.72.433
Gasket adapter (Pos. 2) 102 60.72.435
Gasket adapter (Pos. 2) 201 60.72.445
Drain pipe (Pos. 6) 60.70.735
Silicone hose 2110.1008
Contactor K1/K2 40.03.687
Capacitor 3,5 uF 40.04.151
Capacitor 10 uF 40.04.152
Capacitor 14 uF 40.04.229
Capacitor 40 uF 40.04.230
LED yellow 40.04.165
LED red 40.04.166
Relais kpl. 1U 24V 40.04.304
Differential pressure switch 3017.1014
Control transformer 3037.0253
Voltage related parts for input voltage:
Extractor fan 200-240V (M1) 60.72.439
Extractor fan 100-127V (M1) 60.72.701
