D1) Changing pre filter
- Remove fat filter as described under item 1
- Take out pre filter by lifting it and pulling it out
- Take out pre filter of fiter frame and replace by new
filter
D2) Changing main filter
Attention
The assembly group filter and filter carrier must be
removed completely from the UV Plus.
Observe the weight and the height from which the
assembly group has to be removed.
- Loosen the latches of the filter carrier by pulling
them upwards. Latches are on the top side of
UV Plus. Pic. 19
- Pull the filter carrier to the front side, until it comes
out of the rails completety
- Lift the assembly group Filter off of the UV Plus
- Put the assembly group onto a suitable surface
- Loosen the fixing frame
Pic. 20
- Replace the main filter by the new one.
Pic. 21
- Install the assembly group filter on the UV Plus
- Make sure that the two latches have locked com-
pletely.
Attention:
If the assembly group filter is not installed correctly it
will not work.
Service parts
60.72.428 Main filter
60.72.429 Pre filter ( 5pieces)
