Metra Electronics 70-2054 - Seville 1998-04 W; RPO Code UX8; XLR 2004-08 W; Bose System

INST70-2054
2
CADILLAC
- Seville 1998-04 w/ RPO code UX8
- XLR 2004 w/ Bose System
NOTE
These wire colors do not follow the EIA/Metra color code
A1 Not Used
A2 White/Red Left Rear Speaker (+)
A3 White/Blue Left Rear Speaker (-)
A4 Red Left Dash Speaker (+)
A5 Orange Left Dash Speaker (-)
A6 Gray Center Speaker (-)
A7 Dark Blue/White Center Speaker (+)
A8 Dark Blue Right Dash Speaker (-)
A9 Brown/White Right Dash Speaker (+)
A10 Brown Right Rear Speaker (-)
A11 Blue Right Rear Speaker (+)
A12 Not Used
B1-B12 Not Used
A Not Used
B White Rear Sub (+) (Seville Only)
C Violet Right Front Speaker (-)
D Pink Left Front Speaker (+)
E Light Green Left Front Speaker (-)
F Dark Blue/Pink Right Front Speaker (+)
G Brown/Yellow Rear Sub (-) (Seville Only)
H Not Used
