Metra Electronics 82-9600 - Fairing Disassembly; FLH;Batwing Models Fairing Disassembly

82-9600
Fairing Disassembly
FLH/Batwing models:
1. Cover the front fender.
2. Remove (2) T-27 Torx bolts from inner
fairing (under mirrors) (Figure A, step 2)
3. Remove (2) T-27 Torx bolts from outer
edges of inner fairing near the fork tubes
(facing forward) (Figure A, step 3)
4. Remove (3) T-27 Torx bolts from bottom
edge of windshield. (Figure A, step 4)
NOTE: Windshield and fairing
will be loose once these screws
are removed. Use extreme
caution not to damage fairing or
windshield.
5. Remove windshield taking caution that
the outer fairing is loose.
(Figure A)
Step 2 Step 2
Step 3
Step 4
