82-9600
FLH/Batwing models: (cont.)
6. Lift away and unplug headlight to
remove outer fairing. (Figure B)
7. Unbolt and remove inner fairing support
brackets from each side (3/16” Allen &
T-25 Torx screws).
Note the Torx screw is also a shared
speaker screw. (Figure C)
8.
Remove the remaining speaker
screws and the speaker.
Fairing Disassembly
(Figure B) (Figure C)
