95-3528 DASH DISASSEMBLY
PONTIAC GTO 2004-2006
E
2
Remove (2) Phillips screws exposed
at the bottom of the center panel sur-
rounding radio and remove panel.
(Figure E)
6
Unclip and remove trim panel sur-
rounding radio and A/C controls.
7
Pull down on the "cage" from the
opening inside on the top and
remove.
(Figure G)
9
8
Continue to final assembly.
G
F
Remove (3) Phillips screws holding
"cage" in radio opening.
(Figure F)
To Next Page
