6
Kit Assembly 95-7406
1. Snap the Double DIN brackets to the
inside edge of the Double DIN radio
housing. (Figure A)
2. Slide the Double DIN radio into the
Double DIN bracket/radio housing
assembly and secure the radio to the
assembly using the screws supplied
with the radio. (Figure B)
3. Snap the Double DIN trim-plate onto the
housing/radio assembly. (Figure B)
Note: (2) DIN units could be stacked
using the same process shown above
for Double DIN.
4. Locate the factory wiring harness in the
dash. Metra recommends using the
proper mating adapter from Metra or
AXXESS. Re-connect the negative
battery terminal and test the unit for
proper operation.
5. Reassemble dash in reverse order
of disassembly.
DDIN/Stacked ISO radio
mount provision
(Figure A)
(Figure B)
