95-7419
KIT ASSEMBLY
2005-06 NISSAN ALTIMA
Snap the 95-7419 trim plate into the
radio trim panel.
(Figure A)
1
Slide the stacked ISO DIN units into
the factory brackets and secure the
units to the brackets using the
screws supplied with the head units.
(Figure B)
2
STACKED ISO DIN HEAD UNIT PROVISION
Install the 95-7419 Trim Plate
from Rear
A
B
3
To Next Page
