95-7861 DASH DISASSEMBLY
HONDA PILOT 2003-2005
A
B
1
Disconnect the negative battery-
terminal to prevent an accidental
short circuit.
1
Using a small flat blade screw-
driver remove the blank plate
from upper right side of radio
trim panel. (Figure A)
2
Unsnap radio trim panel. Unplug
switches and remove panel. (Figure B)
3
Remove (4) 10mm bolts securing
radio, unplug and remove radio.
(Figure C)
4
Continue to kit assembly.
C
