2004-2007 MITSUBISHI ENDEAVOR
Disconnect the negative battery terminal
to
prevent an accidental short circuit.
Unsn
ap and remove entire panel sur-
rounding
radio and A/C controls.
(Figure
A)
1
2
Remove
(1) 10MM nut from the rear support
on
the top left of radio on cross bar behind
dash. (FIGURE
B)
3
Remove
(3) Phillips screws to remove
facto
ry radio chassis (Figure C)
4
A
Remove (4) Phillips screws from the pock-
et
at the bottom of the radio and A/C panel
and
remove the pocket. (This is where the
99-7009
will be mounted.) (Figure D)
5
B
C
D
