KIT ASSEMBLY
ISO DIN HEAD UNIT PROVISIONS:
1
Position the aftermarket radio
into audio/climate control/dis-
play bracket assembly and
secure using the bottom (2)
Phillips screw positions and the
factory hardware. (Figure A)
3
Using the factory hardware
secure the factory climate
control button assembly into
the 99-7404.
(Figure C)
4
Using the factory hardware
secure the factory pocket
assembly into the 99-7404.
(Figure D)
A
C
D
99-7404
2
Install the (4) supplied retaining
clips onto the 99-7404 in the
same locations as the factory
radio panel.
(Figure B)
B
