Metra Electronics 99-7612A - Page 7

7
ISO DIN head unit provision with pocket
(Figure D)
(Figure E)
5. Mount the Unified Amp Meter to the
radio/bracket assembly using
(2) supplied 3/8” Phillips screws.
(Figure D)
6. Mount the whole radio/pocket/meter
assembly to the radio trim panel using
(4) supplied 3/8” Phillips screws.
(Figure E)
7. Locate the factory wiring harness
and antenna plug in the dash. Metra
recommends using the proper mating
adapters from Metra and/or AXXESS.
8. Reassemble dash in reverse order of
disassembly.
Kit Assembly 99-7612
