99-7950
3
KIT ASSEMBLY
NOTE
You will need to cut and remove the tabs from the 99-7950 depending on which vehi-
cle you are working with.The tabs are labeled with an (A) for the Aerio and a (V) for the
grand Vitara and XL7. (See photo to right)
NOTE
There are two options to obtain proper fit of the 99-7950 in radio trim panel opening.
OPTION 1
Remove the (2) scored sections from the top (2) corners of
the trim plate that comes with the 99-7950 by using a utility
knife to cut them out.
(Figure A)
OPTION 2
Using a utility knife, remove the two tabs from each side of
the radio opening on the backside of the radio trim pla
te.
(Figure B)
A
B
KIT ASSEMBLY NOTES
