99-8153 KIT ASSEMBLY
B
A
DIN RADIO PROVISION WITH POCKET
Slide the DIN cage into the Radio
Housing and secure by bending the
metal locking tabs outward.
(Figure A)
1
Slide the aftermarket radio into the
cage until it snaps into place.
(Figure B)
2
Continue to final assembly.
*
Note: Refer also to the instructions included with the aftermarket radio.
