Metra Electronics 99-8153 - ISO Mount Radio Installation; ISO Bracket Mounting; Radio into Housing Installation; Trim Plate Attachment

99-8153 KIT ASSEMBLY
B
A
ISO MOUNT RADIO PROVISION WITH POCKET
Mount the ISO Brackets to the radio
with the screws supplied with the
radio. (Figure A)
1
Slide the radio into the radio housing
until it snaps into place. (Figure B)
2
Attach the radio housing trim plate
supplied with the kit to the assembly.
(Figure B)
3
Continue to final assembly.
*
Note: Refer also to the instructions included with the aftermarket radio.
