99-9303
DASH DISASSEMBLY
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
NOTE: Make sure the vent on/off dials
are in the middle position.
1
Using a small flat blade screwdriver,
release the metal clip located inside
the vents facing upward on the left
and right side while pulling the vents
outward from the dash.
(Figure A)
2
A
BMW Z4 2003-2008
B
Remove (2) Phillips screws exposed
at top of radio and remove.
(Figure B)
3
1
